| Network Switch | ||
| Dimensions (L x W x H ) | 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm) | |
| Interface | 5 10/100Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
|
| Power Supply | Max Power consumption: 5W PoE in: Passive PoE PoE in input Voltage: 11-30 V Number of DC inputs 2 (PoE-IN, DC jack) DC jack input Voltage 11-30 V |
|
| Port | 5 | |
| Network Standard | 802.3 af compliant | |
| MAC Address Table | 2K | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
|
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). When total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation. Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, the fanless design ensures quiet operation.
